Name: FSP Group 500W ATX Power Supply PMBus V1.2 Single 1U Size 80 PLUS Plat
Brand: FSP Group
SKU: 47749248975065
Availability: InStock

Main image of FSP Group 500W ATX Power Supply PMBus V1.2 Single 1U Size 80 PLUS Platinum Certified for Rack Mount Case (FSP500-70UDPB) - OEM

Alt view image 2 of 5 - FSP Group 500W ATX Power Supply PMBus V1.2 Single 1U Size 80 PLUS Platinum Certified for Rack Mount Case (FSP500-70UDPB) - OEM

Alt view image 3 of 5 - FSP Group 500W ATX Power Supply PMBus V1.2 Single 1U Size 80 PLUS Platinum Certified for Rack Mount Case (FSP500-70UDPB) - OEM

Alt view image 4 of 5 - FSP Group 500W ATX Power Supply PMBus V1.2 Single 1U Size 80 PLUS Platinum Certified for Rack Mount Case (FSP500-70UDPB) - OEM

Alt view image 5 of 5 - FSP Group 500W ATX Power Supply PMBus V1.2 Single 1U Size 80 PLUS Platinum Certified for Rack Mount Case (FSP500-70UDPB) - OEM

Metodi di pagamento

I tuoi dati di pagamento sono trattati in modo sicuro. Non conserviamo i dettagli della carta di credito né abbiamo accesso alle informazioni della tua carta di credito.

Sicurezza

Learn more about the FSP FSP500-70UDPB

Model
Brand	FSP Group
Model	FSP500-70UDPB

Details
Maximum Power	500W
Output	Output Voltage: +3.3Vdc output : +3.5 Vdc minimum, + 4.8Vdc maximum +5Vdc output : +5.5 Vdc minimum, + 7Vdc maximum +12Vdc output : +13.4 Vdc minimum, + 16Vdc maximum
Input Frequency Range	47 - 63 Hz
Input Current	115V @ 6.3 Amps-rms maximum 230V @ 3.0 Amps-rms maximum
MTBF	The power supply have a minimum predicted MTBF (MIL-HDBK-217) of 100,000 hours of continuous operation at 25 degree C, maximum-output load, and nominal AC inout voltage
Efficiency	> 90%
Hold-up Time	115V / 60Hz 16mSec. Minimum @ 100% Load, 230V / 50Hz 16mSec. Minimum @ 100% Load
Protection	Over current protection 3.3V:50mV p-p 5V:50mV p-p 12V1:120mV p-p 12V2:120mV p-p 12V3:120mV p-p -12V:120mV p-p 5Vsb:50mV p-p

Features
Features	80 Plus Platinum Low Ripple & Noise Output over voltage protection Short circuit protection on all outputs Resettable power shut down INTERNAL 4 cm fan Triple +12V output (+12V/1, +12V/2, +12V/3) 100% burn-in under high ambient temperature (50 degree C) Vacuum-impregnated transformer MTBF:100K hours at 25 degree C 100% Hi-pot tested Line input fuse protection

Dimensions & Weight
Dimensions	1.59" x 8.66" x 3.94"

Environmental
Humidity	Operating : 85% to % RH, Non-condensing Storage : 95% to % RH, Non-condensing
Temperature	Operating : 0 to +50 degree C Storage :-20 to +80 degree C
