FSP FSP180-50PLA 180W Flex ATX 20PIN 4CM BB Fan APFC Power Supply Fuente cooler

Name: FSP FSP180-50PLA 180W Flex ATX 20PIN 4CM BB Fan APFC Power Supply Fuente cooler
Brand: MFerraz
SKU: B000F4C0XG
Price: 366.00 USD
Availability: InStock

Price:

$366.00 USD $563.00 USD

Stock:

In stock

Share this product

Country

Province

Zip code

Duties, Tariffs, Taxes and Customs Fees Everywhere Included. We ship DDP via UPS, FedEx, DHL, USPS, Couriers, Redirectors or the Carrier of your Choice.

We take care worldwide of the import and customs clearance processes. Tariffs, import duties, taxes and customs fees Included everywhere. No extra payments are required.

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Security

POs from Companies, Corporations, Government Agencies (Federal, State, Local), Defense (Military, Air Force, Navy), Health (Hospitals, Laboratories, Clinics), Universities, Schools and Colleges.

FSP FSP180-50PLA 180W Power Supply for Shuttle XPC SK21G, SB51G, SB51GB, SB52G2, SB61G2, SS51G, SS51G1, SS50C, SV24, SV25, FV25, SN45G, SK41G, SN41G2, SN41G2B, SS40G, SK41GPFC, SS56G, SB62G2, SB65G2, SB75G2, SK43G, ST61G4, SB83G5, SB83G5C, SB77G5, SS58G2, SS51G1(v2.0), SS56L, SN95G5, SB86i, SB95P, SD31P, SN25P, SB81P, SK83, SK83G, ST20G5, SN85G, SB61G, SD30G2, PS-X200W, PC40, PC50, Achme AM611BS15S, AM618BS15S, AM630BS20S, ElanVital EVN-1355A, EVN-1216, Enhance ENP-2322B-G, ENP-0812A, ENP-0615B, ENP-0615B-G, FSP FSP180-50PLA1, FSP180-50PLA, FSP200-50PLA, FSP200-50PLA2, FSP150-50PL, FSP150-50PL1R, SOLTEK EQ2000, EQ3701M, Sparkle, TGR, Tiger Power TG-1201, TG-1204

Key Features Warranty 1 Year Output Power 180 W Form Factor Flex ATX Weight 2.5 lbs MTBF 100,000 HOURS @ 25C Ambient Connectors Main 20.pin, P4 4.pin, 3xMolex 4.pin, 1xFDD 4.pin Dimensions WxDxH 81.5 x 125.0 x 40.5 mm Fan Features Quiet 40mm Ball Bearing Fan Detail Specifications FEATURES : -- MAIN 20.PIN FOR LATEST INTEL OR AMD -- FLEX_ATX | P4 | 1U TYPE -- QUIET 40mm BALL.BEARING FAN -- ULTRA.HIGH EFFICIENCY -- ENERGY SAVER -- CASE COVER VENTILATION DESIGN -- ADVANCED THERMAL CONTROL SENSOR -- REPLACE | UPGRADE TO MOST FLEX_ATX -- ON/OFF SWITCH SPECIFICATIONS : -- EFFICIENCY: 70%+ -- LOW RIPPLE | LOW OPERATING NOISE -- OPERATING TEMPERATURE: 0 TO +50C -- STORAGE TEMPERATURE: -20 TO +65C -- HUMIDITY: 10-90% NON.CONDENSING -- OVP: OVER VOLTAGE OUTPUT PROTECTION -- OCP: OVER CURRENT OUTPUT PROTECTION -- SCP: SHORT CIRCUIT OUTPUT PROTECTION -- 100% HI.POT TESTED -- MTBF: 100,000 HOURS @ 25C AMBIENT OUTPUT.CONNECTORS: -- MAIN 20.PIN, P4 4.PIN, (3) MOLEX 4.PIN, (1) FDD 4.PIN INPUT : -- FULL RANGE INPUT U.S. | WORLDWIDE -- PATENTED INPUT FUSE PROTECTION BUILT-IN DIMENSIONS | WEIGHT : -- DIMENSIONS: 125.0Lx81.5Wx40.5H (mm) | WEIGHT : 2.5 LBS -- SHIPPING: 12 UNITS/CARTON | WEIGHT : 32 LBS/CARTON OUTPUT CHART : -- Output Voltage: +3.3V, Min. load: 0.3A, Max. load: 16.8A , Load Reg: ±5%, Ripple & Noise: 50mV P-P -- Output Voltage: +5V, Min. load: 0.3A, Max. load: 12.0A , Load Reg: ±5%, Ripple & Noise: 50mV P-P -- Output Voltage: +12V, Min. load: 1.5A, Max. load: 10.0A , Load Reg: ±5%, Ripple & Noise: 120mV P-P -- Output Voltage: -12V, Min. load: 0.0A, Max. load: 0.3A , Load Reg: ±10%, Ripple & Noise: 120mV P-P -- Output Voltage: +5Vsb, Min. load: 0.0A, Max. load: 2.0A, Load Reg: ±5%, Ripple & Noise: 50mV P-P SAFETY: -- UL, CSA, VDE, NEMKO, TUV, CE, CB, FCC Warranty -- 1 Year
