[shortdesc]
Ruggedized, 3.2 Gbps NGFW, 6 x RJ-45, 2 x SFP/RJ-45 combo, DC-powered, IP40, Fanless
[/shortdesc]
[properties]
| Feature |
Description |
| Form Factor |
Ruggedized 1RU Appliance |
| Storage |
128 GB |
| Passive Cooling |
Fanless design with no moving parts |
| Input Voltage |
12 V–48 VDC |
| Certifications |
IEC 61850-3, IEEE 1613, UL 62368-1, CSA, IEC/EN |
| Temperature Range |
Operating: -40°C to +70°C
Non-operating: -40°C to +70°C |
| Weight |
11 lbs (estimated |
[/properties]
[specifications]
| Specification |
Value |
| Firewall Throughput (AppMix |
3.2 Gbps |
| Threat Prevention Throughput |
1.4 Gbps |
| IPsec VPN Throughput |
2.2 Gbps |
| Max Sessions |
200,000 |
| New Sessions per Second |
10,000 |
| Virtual Systems (Base/Max |
1 / 2 |
| Networking Interfaces |
6x 10/100/1000 + 2x Combo (SFP or Copper |
| Management I/O |
1x RJ45 Console, 1x USB, 1x 10/100/1000 Mgmt |
| Max BTU/hr |
136 |
| Max Current Consumption |
6A @ 12VDC |
[/specifications]
[accesories]
| Accessory |
Description |
| Mounting Kit |
Not explicitly listed; likely standard 1RU mounting rails (consult vendor |
| Power Supply |
External DC power (12–48 VDC; power adapter not included in datasheet |
| Transceivers |
Compatible SFP transceivers for combo ports (sold separately |
[/accesories]
Hardened Security for Harsh Environments
Industrial environments demand more than just performance—they require resilience. The Palo Alto Networks PA-450R is purpose-built to secure ICS/SCADA networks, substations, and field operations exposed to extreme conditions. With fanless design, ruggedized construction, and the power of PAN-OS, the PA-450R delivers dependable, AI-driven protection wherever you need it most.
Key Benefits & Features
High-Performance ML-Powered Firewall
The PA-450R delivers 3.2 Gbps of App-ID-enabled firewall throughput and 1.7 Gbps of threat prevention, ensuring consistent performance even with full security subscriptions enabled. Its Single-Pass Architecture processes traffic efficiently, scanning for threats and applying policies in real-time with minimal latency.
Ruggedized for Industrial-Grade Deployment
Engineered for the harshest environments, the PA-450R operates in temperatures from -40°C to 70°C, complies with IEC 61850-3 and IEEE 1613 standards, and features an IP40-rated enclosure. The fanless, solid-state design eliminates moving parts and reduces failure points, making it ideal for vibration-prone or high-dust areas.
Flexible Connectivity and Fail-Open Reliability
With six RJ-45 ports and two SFP/RJ-45 combo ports, including two fail-open ports, the PA-450R ensures traffic continuity in case of power loss. It's also DC-powered with redundant power support, making it perfect for mission-critical infrastructure.
Advanced Visibility and Control
The device runs PAN-OS 11.1+, offering App-ID, User-ID, SSL decryption, Zero Trust support, and IoT device visibility. Centralized management via Panorama® or Strata™ Cloud Manager enables unified policy enforcement across distributed environments.
Ideal Use Cases
-
Utility substations and energy sites needing secure and rugged edge protection
-
Industrial automation and SCADA networks requiring fanless, temperature-tolerant firewalls
-
Government and defense agencies deploying zero-trust in field conditions
-
Transportation, mining, and oil & gas environments with strict physical durability demands
Technical Specifications
-
Firewall Throughput: 3.2 Gbps
-
Threat Prevention Throughput: 1.7 Gbps
-
Max Concurrent Sessions: 200,000
-
New Sessions per Second: 48,000
-
Ports: 6 x 1G RJ-45, 2 x 1G SFP/RJ-45 combo (includes 2 fail-open
-
Power Input: 12–48 VDC, 39.4 W max
-
Cooling: Fanless
-
Form Factor: 1RU, Wall, Surface, or Rack-mountable
-
Operating Temperature: -40°C to 70°C
-
Dimensions: 44.4 mm H x 390 mm W x 238 mm D
-
Storage: 128 GB onboard
-
Compliance: IP40, IEC 61850-3, IEEE 1613
Secure the Harshest Edges with Confidence
Built for durability and powered by AI, the PA-450R delivers uncompromising security at the edge. Protect your critical infrastructure today. Order now or contact us for expert guidance.
