[shortdesc]
- Expansion module
- 10/100 Ethernet x 8
- for P/N: IE-3000-4TC
- IE-3000-8TC
[/shortdesc]
[properties]
| Properties |
Cisco IEM-3000-8FM |
| Description |
Expansion module, 10/100 Ethernet x 8, for P/N: IE-3000-4TC, IE-3000-8TC |
| Product Family |
Industrial Ethernet 3000 |
| Product Type |
Expansion Module |
| Configurations |
Expansion Fiber module for Cisco IE-3000-4TC and IE-3000-8TC switches
8 100 FX ports |
| Supported Products |
IE-3000-4TC and IE-3000-8TC |
| Dimensions (HxWxD) Inches |
3.5W x 5.8H x 4.4D (89mm W x 147mm H x 112mm D) |
| Weight |
3.2 lb (1.45 kg) |
| Maximum power consumption |
10.1W |
| Mean Time Between Failures (MTBF) |
264,689 |
[/properties][specifications]
| Specifications |
IEM-3000-8FM |
| Operating Temperature |
-40C to +75C
-40C to +70C (Vented Enclosure 40 LFM Air Flow)
-40C to +60C (Sealed Enclosure 0 LFM Air Flow)
-24C to +75C (Fan or Blower equipped Enclosure 200 LFM Air Flow)
-40C to +85C (IEC 60068-2-2 Environmental Type Testing 16 hours) |
| Storage Temperature |
-40 C to +85 C |
| Operating Altitude |
Up to 13,000 ft (3963m) |
| Storage Altitude |
Up to 15,000 ft (4573m) |
| Standard safety certifications |
UL 60950-1
CSA C22.2 No. 60950-1
TUV/GS to EN 60950-1
CB to IEC 60950-1 with all country deviations
NOM
|
| Electromagnetic emissions |
FCC Part 15 Class A
EN 55022
CISPR 22
CISPR11
VCCI Class A
AS/NZS 3548 Class A
CNS 13438 Class A
KN 22 Class A |
| Electromagnetic immunity |
EN 55024
AS/NZS CISPR 24
KN 24
IEC/EN 61000-4-2 (Electro Static Discharge)
IEC/EN 61000-4-3 (Radiated Immunity)
IEC/EN 61000-4-4 (Fast Transients)
IEC/EN 61000-4-5 (Surge)
IEC/EN 61000-4-6 (Conducted Immunity)
IEC/EN 61000-4-8 (Power Frequency Magnetic Field Immunity)
IEC/EN 61000-4-9 (Pulse Magnetic Field Immunity)
IEC/EN 61000-4-10 (Oscillatory Magnetic Field Immunity)
IEC/EN 61000-4-11 (AC power Voltage Immunity)
IEC/EN 61000-4-16 (Low Frequency Conducted CM Disturbances)
IEC/EN 61000-4-17 (Ripple on DC Input Power)
IEC/EN 61000-4-18 (Damped Oscillatory Wave)
IEC/EN 61000-4-29 (Voltage Dips Immunity, DC power)
IEEE C37.90 (Surge)
IEEE C37.90.1 (Fast Transients)
IEEE C37.90.2 (Radiated Immunity)
IEEE C37.90.3 (Electro Static Discharge) |
| Mechanical stability |
IEC 60628-2-27 Shock 20g (operational), 30g (nonoperational)
|
| Industry specifications |
EN 61131-2 Programmable Controllers (EMC/EMI, environmental, mechanical)
IEEE 1613 Power Station and Substation Networking Devices
IEC 61850-3 Power Station and Substation Communication Networks and Systems
EN 61326-1 Electrical Equipment for Measurement, Control and Laboratory Use - EMC
EN 61000-6-1 Immunity for Light Industrial Environments
EN 61000-6-2 Immunity for Industrial Environments
EN 61000-6-4 Emissions for Industrial Environments
TS 61000-6-5 EMC Immunity for Power Station and Substation
EN 50155 Railway, Electronic Equipment on Rolling Stock (EMI/EMC, environmental, mechanical)
EN 50121-3-2 Railway, Electromagnetic Compatibility on Rolling Stock
EN 50121-4 Railway, Emission and Immunity of Signaling and Telecommunications Apparatus
EN 60945 Maritime Navigation and Radio-communication Equipment and Systems
IEC 60533 Shipboard Electrical and Electronic Installation EMC
Marine Type Approval (BV, DNV, Korean Register, Lloyd Register)
NEMA TS-2 (EMC, environmental, mechanical)
ABB Industrial IT certification
ODVA Industrial EtherNet/IP support
PROFINETv2 support
Directive 2011/65/EU RoHS
IP20 |
| Hazardous locations |
UL/CSA 60079-0, -15 (Class 1, Div 2 A-D) (requires cabinet enclosure)
EN 60079-0, -15 ATEX Certification (Class 1, Zone 2 A-D) (requires cabinet enclosure)
IEC 60079-0, -15 (Test report only) (requires cabinet enclosure)
UL 508
CSA C22.2 No. 142 |
| Humidity |
Relative humidity: 5% to 95% non-condensing |
[/specifications]
Cisco IEM-3000-8FM= Expansion Module
The Cisco Industrial Ethernet 3000 Series is designed to comply with a wide range of Industrial Ethernet specifications, making it an ideal choice for industrial automation, ITS, substation, railway, and other markets. The IEM-3000-8FM= is an expansion Fx fiber module for Cisco IE-3000-4TC, IE-3000-8TC, IE-3000-4TC-E, and IE-3000-8TC-E switches.
Key Features:
- 8 x 100-FX ports
-
Cabling Type : Ethernet 100base-
For detailed specifications, refer to the IEM-3000-8FM= datasheet in the tabs.
