[shortdesc] 8-door centralized controller, support for 16 OSDP readers & locks, PoE+ or 12V DC, Axis Edge Vault cybersecurity, DIN-rail mount. [/shortdesc]
[properties]
| Model |
AXIS A1810-B (03079-001 |
| Product Type |
Network Door Controller |
| Number of Doors |
8 doors (Control for up to 16 locks |
| Reader Support |
Up to 16 OSDP readers; 16x ASSA ABLOY Aperio®; Wiegand (via AXIS TA1101-B |
| Credential Capacity |
Up to 250,000 credentials stored locally |
| Event Buffer |
Up to 250,000 events stored locally |
| Power Input |
PoE+ (IEEE 802.3at Type 2 Class 4; DC IN 12 V DC |
| Relay Outputs |
17x Form C Relays (NO/NC Total: 1x Main, 8x Door, 8x AUX |
| I/O Interface |
Digital inputs/outputs; RS485; AUX I/O connectors |
| Memory |
512 MB RAM, 2 GB Flash |
| Network Interface |
RJ45 10/100/1000 Mbps PoE |
| Operating Temperature |
-40 °C to 55 °C (-40 °F to 131 °F |
| Storage Temperature |
-40 °C to 70 °C (-40 °F to 158 °F |
| Humidity |
10–85% RH (operating, 5–95% RH (storage |
| Dimensions |
326.5 mm x 166.1 mm (See dimension drawing for depth |
| Weight |
1330 g (2.9 lb |
| Casing |
Steel; White NCS S 1002-B |
| Mounting |
DIN rail mount; Cabinet mount |
[/properties]
[specifications]
| Reader Connections |
Up to 16 OSDP/RS485 readers (multidrop; OSDP Secure Channel supported; Wiegand via accessory |
| Door Inputs |
REX and door position sensors, 0–30 V DC, supervised (4 states |
| Relay Outputs |
17x Form C relays (NO/NC: Main, Door relays, AUX relays |
| Relay Capacity (Dry |
2 A or 4 A at 30 V DC (depending on relay type |
| Relay Capacity (Wet |
12/24 V DC (jumper configurable; Max 46 W per door group |
| Digital Inputs |
3× digital input (0–30 V DC, supervised |
| Digital Outputs |
3× open drain outputs (0–30 V DC, max 100 mA |
| AUX I/O |
2× configurable I/O (input or output, plus 1x 12 V DC output (max 250 mA |
| External Inputs |
Tamper input; Alarm input (0–30 V DC, supervised |
| Network Protocols |
IPv4/IPv6, HTTP/HTTPS, TLS, DHCP, SNMP v1/v2c/v3, RTSP, QoS, SSH, MQTT, Syslog |
| Cybersecurity |
Axis Edge Vault, Secure Boot, Secure Keystore, Signed Firmware, Brute force delay protection |
| Approvals |
CE, FCC, ICES, KC, RCM, UL/cUL, VCCI, WEEE, UL 294, UL 2043 |
| EMC |
CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50130-4 |
| Safety Standards |
IEC/EN/UL 62368-1; UL 2043; UL 294 |
| Cable Requirements |
Reader RS485 up to 1000 m (AWG 26–14; Power AWG 16–14; Ethernet STP Cat 5e+ |
| Languages |
English, German, French, Spanish, Italian, Russian, Chinese, Japanese, Korean, Portuguese, Polish |
[/specifications]
[accessories]
| Included in the Box |
Door controller; Installation guide; Connector kit (mounted; Grounding kit; Splicing connectors |
| Optional Accessories |
AXIS A9910 I/O Relay Expansion Module; AXIS TA4711 Access Card; AXIS TA4712 Key Fob; AXIS TA1901 DIN Rail Clip; AXIS TA1101-B Wiegand OSDP Converter; AXIS TA1902 Access Control Connector Kit; AXIS 30 W Midspan; AXIS T8006 PS1214 |
[/accessories]
Advanced Multi-Door Control for Scalable, Secure Access
The AXIS A1810-B Network Door Controller delivers centralized, high-density door control designed for enterprise and multisite deployments. Capable of managing up to eight doors and supporting up to sixteen OSDP readers, this unit offers a compact, cost-efficient footprint ideal for both new builds and retrofit access control installations. Featuring built-in lock power management and the robust Axis Edge Vault hardware cybersecurity platform, the A1810-B ensures reliable operation and superior protection against modern cyber threats.
Key Benefits & Features
-
High-Density Door Management: Centralized control for up to eight doors with support for 16 OSDP readers and 16 locks, optimizing installation costs.
-
Secure OSDP Communication: Features OSDP Verified secure channel to ensure tamper-resistant, encrypted bidirectional reader communication.
-
Flexible Power & Integration: Operates via PoE+ or 12 V DC, with integrated power distribution. Supports integration with ASSA ABLOY Aperio® wireless locks.
-
Robust Cybersecurity: Built on the Axis Edge Vault platform, providing secure boot, signed firmware validation, and a hardware-based secure element (CC EAL 6+.
-
Enterprise Scalability: Fully compatible with AXIS Camera Station Secure Entry and third-party software for a unified video and access management system.
Ideal Use Cases
- Large commercial buildings requiring centralized, multi-door access control.
- Critical infrastructure sites demanding UL 294 compliance and OSDP encryption.
- Education, healthcare, and enterprise campuses standardizing on Axis security ecosystems.
- Facilities upgrading from legacy analog systems to modern IP-based architecture.
- High-traffic secure installations requiring massive credential (250k and event storage.
Technical Specifications
-
Door Capacity: Up to 8 doors (2 relays per door supporting double locks.
-
Reader Support: Up to 16 OSDP readers; Wiegand supported via AXIS TA1101-B accessory.
-
Power Input: PoE+ (IEEE 802.3at Type 2 or 12 V DC.
-
Lock Power Outputs: 12/24 V DC jumper-configurable, with multiple protected circuits.
-
Credential Storage: Up to 250,000 credentials stored locally.
-
Event Buffer: Up to 250,000 events.
-
Network: 10/100/1000BASE-T RJ45 with IPv4/IPv6, HTTPS, TLS, SNMP v1/v2c/v3.
-
Cybersecurity: Axis Edge Vault, Secure Boot, Signed Firmware.
-
Operating Temperature: -40 °C to 55 °C (-40 °F to 131 °F.
-
Mounting: DIN rail or Cabinet mount (UL 294 compliant when used with appropriate enclosure.
Enhance Your Access Control Performance
Strengthen your security ecosystem with the AXIS A1810-B Network Door Controller. Order today to secure your facility with industry-leading technology.
